Toroidal coil

TOROIDAL COILS FOR EVERY REQUIREMENT

KUK manufactures customer-specific toroidal core coils with an inner diameter from 3 mm. The core is mainly ferrites from 1.5 mm. Toroidal core coils are used by our customers for switching power supplies, chokes, transformers and many other applications.


OVERVIEW TOROIDAL COIL

KNOW-HOW
  • Miniaturisation
  • Ferritic materials
  • Support for specification of chokes, transmitters, transformers
  • Toroidal core winding equipment
APPLICATIONS
  • Switched-mode power supplies
  • Smoothing and filter chokes
  • Radio interference suppression
  • Oscillating circuits
  • Pulse and broadband transmitters
  • Transformers, inductances
PACKAGING
  • Trays

PRODUCTION OF TOROIDAL COILS

For a toroidal coil, the ideal material depends on the respective application. KUK has a great deal of experience and can provide recommendations as early as the development phase. Toroidal cores matching the ferrite and made of highly qualified plastics in various design variants are also possible. KUK offers custom manufacturing for toroidal coils in all dimensions.

For a toroidal coil, the ideal material depends on the respective application. KUK has a great deal of experience and can provide recommendations as early as the development phase. Toroidal cores matching the ferrite and made of highly qualified plastics in various design variants are also possible. KUK offers custom manufacturing for toroidal coils in all dimensions.

When using customer-specific toroidal coils in applications, these advantages arise:

  • individually tailored to your requirements
  • In-house toolmaking
  • high vertical range of manufacturing
  • one contact for all your requirements

OUR KNOW-HOW AND SERVICES

FEASIBILITY
OPTIMIZATION
SAMPLING
AUTOMATION
SERIES
SCALING

Process partner from product idea to large-scale production

KUK serves the customer according to individual requirements from development phase to the integration of the goods into the global supply chain.
